Assembly, 1 install the handlebar – Echo WT190 Owners Manual v.4 User Manual
Page 8

WHEELED TRIMMER
4
Section
1. Remove the trimmer and handlebar from the shipping box and pallet.
2. Stand handlebar upright. Align the bottom hole on the handlebar with the bottom hole on the handlebar support
channel located on the trimmer and attach with two 5/16" x 1" flange bolts and two 5/16-18" nylock flange nuts.
DO NOT TIGHTEN BOLTS AT THIS TIME.
2
ASSEMBLY
2.1 INSTALL THE HANDLEBAR
