1. STOP SWITCH - Toggle Switch mounted on upper right handle. Move switch forward to "Start" position to run,

back to "Stop" position to stop unit.

THROTTLE TRIGGER - Spring loaded to return to idle when released. When accelerating, pull trigger gradually for
best operating technique. DO NOT hold trigger when starting.

SAFETY DECAL - General safety precautions - See Page 3.

4. SPARK PLUG - Provides spark to ignite fuel mixture.

5. PRIMER BULB - Pumping primer bulb before starting engine draws fresh fuel from the fuel tank priming the

carburetor for starting. Pump primer bulb until fuel is visible and flows freely in the clear fuel tank return line. Pump
bulb an additional 4 or 5 times.

6. CHOKE - The choke control is located on the side of the air filter case. Move choke to "COLD START" to close the

choke for cold starting. Move choke to "RUN" position to open choke.

GEAR BOX - Houses gears for driving tines.

8. AIR CLEANER - Contains replaceable filter element.

9. RECOIL STARTER HANDLE - Pull recoil handle slowly until starter engages, then pull quickly and firmly. When

engine starts, return handle slowly. DO NOT let handle snap back or damage to unit will occur.

10. FUEL TANK CAP - Cover and seals fuel tank opening.

11. FUEL TANK - Contains fuel and fuel filter.

12. TINE GUARD - Used to help deflect debris away from operator and reduce accidental contact with tines.

13. SAFETY DECAL - Safety precautions - See Page 3.

14. TINES - Special 10-tooth tines are reversible for tilling or cultivating, removable for cleaning.

15. PLASTIC CARRYING HANDLE - Use to lift and carry unit.

16. SPARK ARRESTOR - CATALYTIC MUFFLER / MUFFLER -The muffler or catalytic muffler controls exhaust noise

and emission. The spark arrestor screen prevents hot, glowing particles of carbon from leaving the muffler. Keep

exhaust area clear of flammable debris.
