PAS-225VP SPECIFICATIONS
© 12/2013 ECHO Inc.
X7722273906 35
SPECIFICATIONS
MODEL PAS-225 Value Pack
Length 1793 mm (70.6 in.)
Width 251 mm (9.88 in.)
Height 328 mm (12.9 in.)
Weight (dry) 5.75 kg (12.68 lb.)
Engine Type Air cooled, two-stroke, single cylinder gasoline engine
Bore 32.2 mm (1.27 in.)
Stroke 26.0 mm (1.02 in.)
Displacement 21.2 cc (1.29 cu. in.)
Exhaust Spark arrestor muffler or spark arrestor muffler with catalyst
Carburetor Diaphragm w/purge pump
Ignition System Flywheel magneto, capacitor discharge ignition type
Spark Plug NGK BPM-8Y (Gap 0.65 mm (0.026 in.)
Fuel Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio
50 : 1 Power Blend X TM ISO-L-EGD (ISO/CD 13738) and J.A.S.O. M345- FD, two-stroke,
air-cooled engine oil.
Gasoline
Use 89 Octane unleaded. Do not use fuel containing methyl alcohol, more than 10% ethyl
alcohol or 15% MTBE. Do not use alternative fuels such as E-15 or E-85.
Oil Power Blend X TM Premium Universal 2-Stroke Oil
Fuel Tank Capacity 0.44 lit. (14.9 US fl. oz.)
Starter System i-30 Automatic Rewind Starter
Clutch Centrifugal Type
Drive Shaft (upper & lower) 6.35 mm (1/4 in.) flexible shaft
Rotating Direction Counter Clockwise; viewed from top
Trimmer Attachment Speed Feed® 400 LH Nylon line head, Line capacity 6.0 m (20 ft.)
Handles Front - Loop, Rear Handle (w/rubber)
Shoulder Harness Optional
Edger Attachment
- Shaft Length 845 mm (33.25in.)
- Attachment Width 165.1 mm (6.50 in.)
- Attachment Height 552.45 mm (21.75 in.)
- Weight w/blade 2.54 kg (5.6 lb.)
- Drive Shaft Type 6.35 mm (1/4 in.) Flex Shaft
- Rotation Direction Clockwise viewed from right side
- Blade Length 203 mm (8 in.)
- Gear Case Ratio 2.07 : 1.0 Reduction
- Shield Open, anti-clog
Idle Speed 2,750 RPM
Clutch Engagement Speed 3,800 RPM
Wide Open Throttle Speed (W.O.T.)
w/Nylon Line Head 8,150 RPM
w/Edger Attachment 10,500 RPM
