TECHNICAL DATA CS-330T
TECHNICAL DATA
* Technical data subject to change without notice.
Model CS-330T
Length 277 mm (10.9 in.)
Width 247 mm (9.7 in.)
Height 214 mm (8.4 in.)
Dry weight 3.6 kg (7.9 lb.) Without chain and guide bar
Engine Air-cooled two-stroke single cylinder
Displacement 32.6 mL (1.989 cu. in.)
Bore 36.0 mm (1.417 in.)
Stroke 32.0 mm (1.259 in.)
Compressions ratio 7.5 : 1
Carburetor Diaphragm type
Spark plug NGK BPM8Y
Fuel tank capacity 310 mL (10.5 US. fl. oz.)
Fuel
50 : 1 ratio with ECHO Power Blend X™, ISO-L-EGD (ISO/CD 13738) and JASO
M345-FD two-stroke, air-cooled engine oil.
Gasoline
Use 89 octane unleaded. Do not use fuel containing methyl alcohol, more than 10 %
ethyl alcohol or 15 % MTBE. Do not use alternative fuels such as E-15 or E-85.
Oiling system Adjustable automatic oiler
Chain oil capacity 290 mL (9.8 US. fl. oz.)
Starter system Automatic rewind starter
Clutch Centrifugal type
Sprocket type Spur type, 6-tooth, 3/8 in. pitch
Chain brake Automatic band brake type
Idle speed 2,600 RPM
Clutch engagement speed 4,300 RPM
Wide open throttle speed
(W.O.T.) 13,500 RPM
Chain tensioner Side access system
Guide bar 12, 14, 16 in
Saw chain 91PX/91VG
Standard features
Top handle, Front hand guard, Anti-vibration device, Throttle control lockout, Chain
catcher, Spark arrestor catalytic muffler
Kickback safety features Double Guard Low Kick Guide Bar, Low Kick Guard Link Saw Chain, Front Hand
Guard/Chain Brake Lever, Tip Guard
