Wireless Configuration - WPA/WPA2
Select your Network Type from the drop 1.
down menu.
Type in the SSID for the wireless network.
2.
This is the name of your wireless network.
Select your Secuity System between
3.
WPA or WPA2. This would be determined
by the type of wireless network security
that was setup when the router was
configured. Then choose the Key Format
for your wireless network password. Then
enter the Pre-Shared Key, this is the pass
key for your wireless network. Finally
choose the Encryption type that was
setup for the pass key.
Scroll down and press the Submit. Allow
4.
the GWUIP204 to restart and come back
to the login screen. Then the GUWIP204
can be powered off and disconnected
from the hard wired connection. You
can then power on the GUWIP204 and
the device should recognized by the
GUWIP204 software.
