Hardware installation – IOGear GUIP204 v2 User Manual
Page 7
6
7
NOTE: Before you connect your USB device to the network, please refer to the device’s user
manual and install the device’s driver and required software under the USB connection first.
When the installation is completed, safely remove your USB devices from the system. Discon-
nect the power source from USB devices and GUIP204 USB Sharing Hub.
Connect your USB device to any one of the USB ports of the USB Sharing Hub.
1.
Hardware Installation
Ethernet
Reset
12Vdc 5A
USB device (not included)
