Package Content
CE Compliance
Product Overview
Hardware Installation
DC 5V Micro USB 3.0
1 x SuperSpeed USB 3.0 4-Port Hub
1 x SuperSpeed USB 3.0 Cable (Micro-B to Standard-A)
1 x Power Adapter
1 x Quick Start Guide
1 x Warranty Card
1. Power indicator LED
2. USB 3.0 Micro-B port
3. Power jack
4. USB 3.0 Standard-A ports
PC
• Windows XP, Windows Vista, and
Windows 7
• Available USB port (USB 3.0 port for
SuperSpeed mode)
1. Plug the AC Power Adapter into a power outlet and the opposing end of the
cable into the hub’s AC power jack
2. Connect the hub to your computer using the included USB 3.0 cable
• Plug Micro-B connector, labeled “B” on connector, into the hub
• Plug the Standard-A connector, labeled “SS” on connector, into your
computer’s SS USB 3.0 port.*
Mac
• Works with USB 2.0 and 1.1
1
2 3 4
DC 5V
Micr o USB
3.0
* Hub is compatible with USB 3.0, 2.0, and 1.1.
** SuperSpeed rates are possible when hub is plugged into a computer’s USB 3.0
port and the peripherals connected to the hub are USB 3.0 devices.
3. Red LED light will indicate hub is receiving power
4. Plug the USB devices** you wish to connect to your computer into the hub
