Hardware Installation
1. Open your computer case, touch any metal part of the case to ground
yourself. Insert the GIC320U into an available PCI Express Card™ slot (refer
to your computer’s manual for more instructions). You may use the included
Low-Profile bracket for a system with a low-profile chassis.
Note: Depends on your computer’s power supply design, you may choose to
connect the power connector on GIC320U with the power cable from the
power supply.
2. Plug in and turn on your computer. When Windows starts, it should load the
driver you just installed automatically.
3
Attaching Screw
Bracket
GIC320U
PCI-Express Slot
Motherboard
System Frame
