Overview
PC 1 LEDs 1.
PC 2 LEDs 2.
Console USB Mouse Port 3.
Console HD Port 4.
Console USB Keyboard Port 5.
Console Audio Port 6.
Console Mic. Port 7.
CPUs Audio connection 8.
CPUs USB Keyboard connection 9.
CPUs HD connection 10.
CPUs USB Keyboard connection 11.
CPUs Mic. connection 12.
Remote Switch Button 13.
8
10
9 11 12 13 4
2
3
1
5 6 7
