5
System Requirements
Recommended Console
• Display Option #1 – A display with both DVI and VGA connection*
• Display Option #2 – A DVI-I Display
• Display Option #3 – One each of DVI and VGA displays
• 1 set of USB keyboard and mouse
Computers
• 1 DVI port or 1 VGA port
• 1 USB port
Operating Systems
• Windows XP, Windows Vista (32-bit / 64-bit)
• Windows 7 (32-bit / 64-bit)**
• Mac OS X v10.3.9 or later
• Sun Solaris
• Linux
*IOGEAR recommends Display Option #1 for the best display configuration
**IOGEAR's Display Emulation Technology provides the EDID support for Windows 7
Cable
Only custom USB DVI or VGA KVM cable sets, which are specifically designed to work with
this switch, may be used to link to the computers. Two cable sets are provided with this
package.
Note: The quality of the display is affected by the quality and length of the cables. If you need
additional cable sets, please contact your dealer to purchase the appropriate ones for your switch.
Package Contents
1 x 8-port USB DVI KVMP Switch
2 x Custom USB DVI-D KVM Cable Sets
1 x Firmware Upgrade Cable
1 x Power Adapter
1 x Foot Pad Set (4 pcs)
1 x User Manual
1 x Rack Mount Kit
1 x Warranty Card
Type Length Part Number
USB DVI-D Single Link
6ft (1.8m) G2L7D02U
10ft (3.0 m) G2L7D03U
16ft (5.0 m) G2L7D05U
USB DVI-I Single Link* 6ft (1.8 m) G2L7D02UI *
10ft (3.0 m) G2L7D03UI
*For cascading setup, IOGEAR recommends to use USB DVI-I Single Link cable
(G2L7D02UI) for GCS1108, and G2L7D02UD for GCS1208.
Tyep Length Part Number
USB DVI-D Dual Link
6ft (1.8m) G2L7D02UD
10ft (3.0 m) G2L7D03UD
16ft (5.0 m) G2L7D05UD
USB VGA Cable 6ft (1.8m) G2L5102U
DVI-A Adapter GDVIMVGAF
