Text mode
Original mode

1. Bring the KVM focus to the port you want to set.
2. Invoke HSM.
3. Press and release the appropriate Function key (see table below).

After completing this procedure, you automatically exit HSM.

The PC compatible (101/104 key) keyboard can emulate the functions of Mac and Sun keyboards when
the Control key [Ctrl] is used in conjunction with other keys. The emulation mappings are listed in the table
on the next page.

Function Key

Operation

[F2]

Enables Mac keyboard emulation, see Mac Keyboard Emulation,

[F3]

Enables Sun keyboard emulation, see Sun Keyboard Emulation

[F10]

Disables keyboard emulation. Key presses are passed straight through. When your console

uses a Mac keyboard to access a Mac attached to a port, for example
