SECTION 6 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE
3121647 – JLG Lift – 6-3
Tires
Dimensional Data
Table 6-3. Tire Specifications
Size IN240/55-17.5 IN240/55-17.5 26x7x20
Load Range E E N/A
Ply Rating 10 10 N/A
Tire Pressure 90 psi (6.2 Bar) Foam-Filled Solid
Table 6-4. Dimensional Data
Machine Length (stowed)
E450A
M450AJ, E450AJ
18 ft. 8.0 in. (5.69 m)
21 ft. 2 in. (6.45 m)
Up and Over Platform Height
E450A
M450AJ, E450AJ
24 ft. 7 in. (7.49 m)
25 ft. 3 in. (7.7 m)
Horizontal Reach @ Maximum Up and
Over
E450A
M450AJ, E450AJ
23 ft. 1 in. (7.0 m)
23 ft. 9 in. (7.24 m)
Machine Width 5 ft. 9 in. (1.75 m)
Wheel Base 6 ft. 7.0 in. (2.00 m)
Working Height 51 ft. 0 in. (15.54 m)
Platform Height 45 ft. 0 in. (13.72 m)
Track Width 5 ft. 0 in. (1.51 m)
Tail Swing (Any Position) 0
Ground Clearance
E450A
M450AJ, E450AJ
8.5 in. (0.22 m)
8 in. (0.20 m)
Table 6-4. Dimensional Data
