JLG 600SC_660SJC Parts Manual User Manual
Page 186
7-14
SECTION 7 ELECTRICAL
606K
4460884
1
Plug, Male - 4 Position
4460465
2
Socket, Female
4460942
2
Socket, Female
606L
1001142938
1
Plug, Male - 2 Position
1001142940
2
Terminal, Female
1001142941
2
Seal
606M
1001133714
1
Plug, Male - 4 Position
1001133715
3
Terminal, Female
1001135650
3
Seal
4461008
1
Plug, Cavity (was p/n 1001135651)
606N
1001126362
1
Receptacle, Female - 62 Position
1001126363
33
Terminal
1001126364
33
Seal
1001126391
23
Plug
4461008
4
Plug, Cavity
1001126365
2
Terminal
4461054
2
Seal
607
1001143907
1
Alternator Power Cable
1001098764
1
Boot, Red
608
See Note
1
Pump Harness (Note: Not Available for Purchase.)
608A
7007497
1
Plug (Pump End)
608B
7007498
1
Plug (Engine Harness End)
609
4360506
1
Broken Cable Proximity Switch Harness (Includes Switch)
(Australian & CE Specs Only)
610
4360517
1
Switch, Proximity
610A
4460320
1
Connector - 2 Position
4460227
2
Pin, Male
Ref.
OPTIONAL HARNESS COMPONENTS
701
AC to Platform Receptacle Components Options:
Note: For use with 2500W Generator Only.
ANSI, ANSI Export & Japanese Specs Options:
0256113
Ref.
110V/60Hz GFI Receptacle
B
0257175
Ref.
220V Receptacle
B
0256201
Ref.
Australian, Brazilian & Latin America Specs (110V/50Hz)
3
Ref.
CE Spec Options Only:
0256201
Ref.
110V/50Hz Receptacle (No Plug)
B
1001100390
Ref.
220V with CEE 7 Post Ground Receptacle & Plug & Circuit
Breaker (2x4 Box) (With Powermite Control Box)
E
0275455
Ref.
220V with CEE 7 Post Ground Receptacle & Plug & Circuit
Breaker (2x4 Box) (Without Powermite Control Box)
E
1001100391
Ref.
220V with CEE 7 Side Ground Receptacle & Plug & Circuit
Breaker (2x4 Box) (With Powermite Control Box)
E
0275456
Ref.
220V with CEE 7 Side Ground Receptacle & Plug & Circuit
Breaker (2x4 Box) (Without Powermite Control Box)
E
1001100392
Ref.
220V with AFSINT 107 Keyed Ground Receptacle & Plug &
Circuit Breaker (2x4 Box) (With Powermite Control Box)
D
0275659
Ref.
220V with AFSINT 107 Keyed Ground Receptacle & Plug &
Circuit Breaker (2x4 Box) (Without Powermite Control Box)
E
FIGURE 7-2. HARNESS COMPONENTS INSTALLATION (CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
