SECTION 1 - SPECIFICATIONS
3120762
– JLG Lift –
1-1
SECTION 1. SPECIFICATIONS
1.1
CAPACITIES
Hydraulic Oil Tank
1532E3/1932E3
3.7 gallons (14.0 liters)
2033E3/2046E3
3.35 gallons (12.7 liters)
2646E3/2658E3
3.35 gallons (12.7 liters)
Hydraulic System (Including Tank)
1532E3/1932E3 - Approximately 4.75 gallons (17 liters)
2033E3/2046E3 - Approximately 5.25 gallons (20 liters)
2646E3/2658E3 - Approximately 5.75 gallons (22 liters)
1.2
COMPONENT DATA
Hydraulic Pump/Electric Motor Assembly
24 Volts DC motor w/single section gear pump
All models 3.0 gpm (11.4 lpm)
Battery Charger
20 Amp SCR
120/240 Volts AC - 50 Hz input
24 Volts DC - 20 Amp output w/auto timer
Japanese Specification
100/200 Volts AC - 50/60 Hz input
24 Volts DC - 20 Amp output w/auto timer
Batteries (4)
All models - 6 Volt, 220 Amp Hour
Optional - (2033E3/2046E3/2646E3/2658E3) 6 Volt, 245
Amp Hour
Steer/Drive System
TIRES - 1532E3/1932E3
Standard - 4.50 x 14.00 - Solid, Non-Marking
Optional - 4.50 x 14.00 - Solid, Rib
TIRES - 2033E3/2046E3/2646E3/2658E3
Standard - 5.00 x 16.00 - Solid, Non-Marking
Optional - 5.00 x 16.00 - Solid, Rib
Optional (2046E3/2646E3/2658E3) - 7.50 x 16.00 - Solid,
Flotation Tread
PARKING BRAKE - Single cylinder, spring applied,
hydraulically released
DRIVE MOTORS
1532E3/1932E3 - 9.9 in[3] (160 cm[3]) displacement
2033E3 - 14.0 in[3] (225 cm[3]) displacement
2046E3/2646E3/2658E3 - 16.2 in[3] (265 cm[3]) displace-
ment
Hydraulic Filter - Inline
Return - Bypass Type
10 Microns Nominal
Platform Size
1532E3/1932E3 - 30 in x 64 in (0.8 m x 1.6 m)
2033E3 - 30 in x 94 in (0.8 m x 2.4 m)
2046E3/2646E3 - 42 in x 94 in (1.1 m x 2.4 m)
2658E3 - 54 in x 94 in (1.4 m x 2.4 m)
1.3
PERFORMANCE DATA
Travel Speed
1532E3/1932E3.
Low Speed - 1.3 mph (2.1 kmh)
Elevated Speed - 0.5 mph (0.80 kmh)
Maximum Speed - 2.3 mph (3.7 kmh)
2033E3.
Low Speed - 1.5 mph (2.1 kmh)
Elevated Speed - 0.5 mph (0.80 kmh)
Maximum Speed - 2.4 mph (3.9 kmh)
2046E3.
Low Speed - 1.3 mph (2.1 kmh)
Elevated Speed - 0.5 mph (0.80 kmh)
Maximum Speed - 2.4 mph (3.9 kmh)
