2-5
SECTION 2 TURNTABLE
11
1
Articulating Jib Valve Kit (See Figure 2-3 for Breakdown)
Options:
Not Required
600A - 2WS/600A - 4WS
4640921
600AJ - 2WS/600AJ - 4WS
4921927
Harness, Articulating Jib (Not Shown - See Section 7 for
Breakdown)
12
1
4WS Valve Assembly (See Figure 2-3 for Breakdown) Options:
Not Required
600A - 2WS/600AJ - 2WS
4640922
600A - 4WS/600AJ - 4WS
4921928
1
Harness, 4WS (Not Shown - See Section 7 for Breakdown)
13
0641613
2
Bolt 3/8in-16NC x 1-5/8in
14
4711600
A/R
Flatwasher 3/8in Thin
15
Not Used
16
4891800
2
Flatwasher 1/2in Hardened (S/N 0300069000 to
S/N 0300074392)
17
4711500
A/R
Flatwasher 5/16in Thin
18
2
Hardware Options:
3311501
Nut 5/16in-18NC (S/N 0300069000 to S/N 0300074392)
0641514
Bolt 5/16in-18NC x 1-3/4in (S/N 0300074392 to
S/N 0300087000)
19
0651406
A/R
Bolt 1/4in-28NF x 3/4in
20
4711400
A/R
Flatwasher 1/4in Thin
21
1
Return Filter Assembly Options:
2120145
S/N 0300069000 to S/N 0300084829
B
2120164
S/N 0300084829 to S/N 0300087000
B
21A
2120149
1
Element, Filter
21B
7016313
1
Switch, Clog Indicator - p/n 2120145
7020021
1
Manual Indicator - p/n 2120164
22
2220893
1
Fitting, Adaptor
23
0641416
2
Bolt 1/4in-20NC x 2in
24
4891400
4
Flatwasher 1/4in Hardened
25
3311405
A/R
Locknut 1/4in-20NC
26
0140001
1
Horn
27 to 28
Not Used
29
0641522
2
Bolt 5/16in-18NC x 2-3/4in (S/N 0300069000 to
S/N 0300070977)
30
0641414
2
Bolt 1/4in-20NC x 1-3/4in
31
0641608
3
Bolt 3/8in-16NC x 1in
32
3311505
2
Locknut 5/16in-18NC (S/N 0300069000 to S/N 0300070977)
33 to 36
Not Used
37
1380136
2
Clip, Gripper (S/N 0300069000 to S/N 0300070977)
38
3910806
2
Screw #8 x 3/4in (S/N 0300069000 to S/N 0300070977)
39
4750800
4
Flatwasher #8 Regular(S/N 0300069000 to S/N 0300070977)
40
3310805
2
Locknut #8 (S/N 0300069000 to S/N 0300070977)
41
2560122
1
Handle (S/N 0300069000 to S/N 0300070977)
42
2560123
1
Grip, Handle (S/N 0300069000 to S/N 0300070977)
43
0100011
A/R
Compound, Locking
44
4060804
16in/40cm
Trim-Loc 3/16in
45
4060918
79in/1.9m
Trim-Loc 5/8in
46
4060807
18in/46cm
Trim-Loc 3/8in
FIGURE 2-1. CONTROL VALVES INSTALLATIONS (CONTINUED)
