2-16 15MVL 15MSP 20MVL 20MSP 3121232
SECTION 2 CONTROLS
208 3311405 2 Locknut 1/4in-20NC
209 3311505 2 Locknut 5/16in-18NC
210 to 212 Not Used
213 4711400 AR Flatwasher 1/4in
214 4711500 2 Flatwasher 5/16in
215 Not Used
Ref CHARGER PLUG INSTALLATIONS (ANSI & ANSI EXPORT
SPECS)
1001096871 Ref Charger Plug 110V (ANSI, ANSI Export & CSA Spec) B
1001096899 Ref Charger No Plug (ANSI Export Spec) B
301 3311001 AR Nut #10-24NC
302 3911016 AR Screw #10-24NC x 1in
303 4460802 1 Cover, Terminal
304 AR Receptacle and Boot
4460803 1 USA ANSI Spec Receptacle
See Note 0 Country Spec Receptacle (Note: Not Available - Purchase
Locally)
305 4761000 AR Lockwasher #10
401 Use 2915230 1 BATTERY CHARGER REPROGRAM CONTROLLER KIT
(was p/n 1600466)
FIGURE 2-5. BATTERIES/CHARGER/SWITCHES INSTALLATION (4-6VOLT BATTERIES)
(CONTINUED)
ITEM # PART NUMBER QTY. DESCRIPTION REV.
