9-2
SECTION 9
RECOMMENDED SERVICE
PARTS STOCK
1600443
Module (Engine) (Figure 2-6)
1
4360070
Breaker, Circuit (7500W SkyPower Generator Option) (Figures 2-11 & 2-12)
1
2400064
Fuse - 5 Amp (7500W SkyPower Generator Option) (Figure 2-12)
2
1001110940
Breather, Hydraulic Oil Tank (1100S) (Figure 2-13)
12
7024444
Breather, Hydraulic Oil Tank (1100SJP without Hostile Environment Package)
(Figure 2-13)
12
1001110940
Breather, Hydraulic Oil Tank (1100SJP with Hostile Environment Package)
(Figure 2-13)
12
1001110084
Module, Ground Control (Figure 2-17)
1
1001133329
Sensor, Angle Indicator (Figure 3-5)
1
4360548
Switch, Jib Limit (11000SJP Only) (Figure 3-5)
1
4360527
Switch, Cable Break (Figure 3-5)
1
4360543
Sensor, Boom Length (Figure 3-5)
1
2940074
Latch, Platform (1100SJP Only) (Figure 4-2)
1
1600343
Module, Platform Control (Figure 4-3)
1
4360232
Breaker, Circuit (Platform Worklights Option) (Figures 4-3 & 7-5)
1
4360522
Switch, Push Button (Chassis Illumination Lights Option) (Figure 4-3)
1
2400070
Fuse (Platform Worklights Option) (Figure 7-5)
2
MODELS 1100S & 1100SJP
The following list will service one machine (built to current production per date on the front cover) with emergency repair
parts which can be installed in the field. Parts from the list should be replaced when inventory is depleted to keep service
parts stock supplied. For further information, contact your JLG dealer or the JLG Industries Parts Department.
Part Number
Description
Qty./Machine
