4-10 150HAX 3120812
SECTION 4 PLATFORM
109
0080098
1
Adapter, Motor to Worm Gear
110
2440044
1
Gear, Worm
111
4740256
2
Washer, Thrust
112
0440135
1
Bearing, Sleeve
113 1760068 1 Disc, Brake
114
Not Used
115
3931010
5
Bolt, Socket Head #10-24NC x 5/8"
116
3441228
2
Rollpin 3/8" x 1 3/4"
117
3931620
2
Bolt, Socket Head 3/8"-16NC x 1 1/4"
118
4761600
6
Lockwasher 3/8"
119 3931612 4 Bolt, Socket Head 3/8"-16NC x 3/4"
120 4070585 A/R Shim .010
121 3311005 A/R Shim .005
122 4070587 A/R Shim .002
123
0100019
A/R
Compound, Locking
124 0100021 A/R Primer
125
2160001
1
Fitting, Grease - 90°
126
3020025
A/R
Grease
3510841 Ref. PLATFORM ASSEMBLY - 36in x 96in (.9m x 2.44m) 3
201 3510839 1 Platform Weldment - 30in x 96in (.7m x 2.4m)
201A 1780253 1 Door Weldment
201B 2940006 1 Latch, Door
2560010 1 Handle, Latch
201C 2160006 2 Fitting, Grease
202 to 205 Not Used
206 3534144 2 Kickplate (Ends)
207 0721003 36 Screw, Machine #10-24NC x 3/8”
208 4740371 72 Washer, Special
209 3311005 36 Locknut #10-24NC
FIGURE 4-2. PLATFORM AND ROTATOR INSTALLATION (S/N 76169 TO PRESENT)
ITEM # PART NUMBER QTY. DESCRIPTION REV.
