JLG GM Engine Supplements User Manual
Page 12
2-4
SECTION 2 .97L ENGINE
FIGURE 2-1. SHORT BLOCK COMPONENTS
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
Ref
PISTON/CRANKSHAFT COMPONENTS
1
70003244
4
Ring, Piston
2
70003245
4
Piston
3
70003246
4
Pin, Piston
4
70003247
8
Clip
5
70003248
4
Rod, Connecting
70003249
8
Bolt, Connecting Rod
70003250
8
Nut, Connecting Rod Nut
6
70003251
8
Bearing, Rod
7
70003252
1
Crankshaft
8
70003253
1
Bolt
9
70003254
1
Ring
10
70003255
1
Gear, Timing
11
70003256
1
Washer
12
70003257
1
Key
13
70003258
2
Bearing
14
70003259
10
Bearing, Crankshaft
15
70003260
1
Gasket
16
70003261
2
Pin, Dowel
17
70003262
1
Gasket, Rear Oil Seal Housing
18
70003263
1
Housing, Rear Oil Seal
19
70003264
2
Bolt
20
70003265
1
Seal, Rear Oil
21
70003266
4
Bolt
22
70003267
1
Seal, Front Oil
23
See Note
1
Ring (Note: Not available for purchase)
24
Use I70003253
1
Washer
Ref
OIL PAN COMPONENTS
101
See Note
1
Pan, Oil (Note: Not available for purchase)
102
70003268
1
Gasket, Oil Pan
103
70003269
18
Bolt
104
70003270
1
Plug, Oil Pan (Note: See Dress Kit before ordering parts)
105
70003271
1
Seal, Oil Pan Plug
106
70003272
1
Gasket, Strainer
107
70003273
1
Strainer, Sump
108
70003274
2
Bolt
Ref
OIL PUMP COMPONENTS
201
70003275
1
Block, Oil Pump
202
70003276
1
Plug
203
70003277
1
Gear, Oil Pump Inner
204
70003278
1
Gear, Oil Pump Outer
205
70003279
1
Valve, Oil Pressure Relief
206
70003280
1
Spring, Oil Pressure Relief
207
70003281
1
Plug, Oil Pressure Relief
