SECTION 3 - USER RESPONSIBILITIES AND MACHINE CONTROL
3120764 – JLG Lift – 3-9
d. There is some other fault in one of the circuits. If
so determine the cause by counting the flash
code, a number of flashes followed by a pause
followed by another number of flashes, and refer
to the service manual.
NOTE: The engine will automatically shut down under the
following conditions:
High Engine Oil Temperature
Low Engine Oil Pressure
Engine Overspeed
Generator Overvoltage
14. Generator Enable Control.
The Generator Enable control switch, when in the off
position, allows the operator to prevent the genera-
tor engine from starting when using the machine
indoors. When in the on position (and the ground
Emergency Stop Switch on [pulled out]), the gener-
ator is enabled to automatically start when the bat-
teries need charged.
15. Horn.
A push-type HORN switch supplies electrical power
to an audible warning device when pressed.
16. Circuit Breakers.
The circuit breakers open (pop out) to indicate a
short or overload somewhere on the machine.
17. 110 Volt AC Outlet.
This feature allows electrical power to be supplied to
the platform. Plug an extension cord into a
grounded 110 VAC outlet and then into the plug on
the right side of the hood. Power will now be sup-
plied to the outlet in the basket to run portable elec-
tric tools, lights, etc.
TO AVOID SERIOUS INJURY, DO NOT OPERATE MACHINE IF ANY
CONTROL LEVERS OR TOGGLE SWITCHES CONTROLLING
PLATFORM MOVEMENT DO NOT RETURN TO THE OFF POSITION
WHEN RELEASED.
Table 3-1.Simultaneous Functions
If This Function is Selected: These Functions Will Also Work at the Same Time:
Drive and Steer Swing Lower Lift** Upper Lift** Telescope
Swing Drive and Steer Lower Lift** Upper Lift** Telescope
Lower Lift Drive and Steer Swing* No Telescope*
Upper Lift Drive and Steer Swing No Telescope
Telescope Drive and Steer Swing* Lower Lift** Upper Lift**
Jib Drive and Steer Swing* Lower Lift** Upper Lift** Telescope
Platform Rotate Drive and Steer No No No No
Note: Boom functions may be slower when selected with another function than when operated individually, due to sharing of oil.
* These functions may move very slowly (or not at all) if the first function selected (Lower Lift or Swing) is being operated at full speed, due to sharing of oil.
** Lower Lift and Upper Lift will not function simultaneously. Upper Lift always prevails.
Updated 5-7-99
