Page 136
6-4
SECTION 6 HYDRAULIC
FIGURE 6-1. HYDRAULIC INSTALLATION
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
Ref.
HYDRAULIC INSTALLATION
1001115785
Ref.
Machines without Arctic Package
F
1001120430
Ref.
Machines with Arctic Package
D
1 to 2
Not Used
3
2110808
8
Fitting, Straight
4
2131216
2
Fitting, 90°
5
2220365
2
Fitting, 45°
6
2220366
1
Fitting, 90°
7
2220371
4
Fitting, Straight
8
2220373
1
Fitting, Straight
9
2220374
2
Fitting, Straight
10
Not Used
11
2220415
23
Fitting, Straight
12
2220451
2
Fitting, Straight
13
2220466
6
Fitting, 90°
14
2220468
2
Fitting, Straight
15
2220472
6
Fitting, 90°
16
2220473
8
Fitting, 90°
17
2220499
1
Fitting, 45°
18
2220501
4
Fitting, 45°
19
2220502
2
Fitting, 45°
20
2220507
1
Fitting
21
2220582
2
Fitting, Straight
22
2220819
1
Fitting, 90°
23
2220828
2
Fitting, 90°
24
Not Used
25
2220947
2
Fitting, Straight
26 to 27
Not Used
28
2221041
1
Fitting, Tee
29
2221053
1
Fitting, Tee
30
2221060
1
Fitting, Tee
31
2221086
7
Fitting, Test
32
Not Used
33
4240018
7
Tie-Strap (Not Shown)
34
77133089
2
Mini Check
35
80633030
2
Clamp, Hose
36
1001116905
1
Tube, Steel
37
1001119035
1
Hose
38
1001119068
1
Hose
39
1001119069
1
Hose
40
1001119070
1
Hose
41
1001119071
1
Hose
42
1001119143
1
Hose
43
1001119237
1
Hose
44
1001119324
1
Hose
45
1001119365
1
Hose
46
1001119404
1
Hose
47
1001119449
1
Hose
