SECTION 1 - SPECIFICATIONS
3120849 – JLG Lift – 1-1
SECTION 1. SPECIFICATIONS
1.1 CAPACITIES
System Voltage
All VP Models –24 Volt DC (2 - 12 volt DC batteries)
Hydraulic Oil Reservoir
All VP Models – 4.7 ltr. (5 qts. U.S.)
1.2 COMPONENT DATA
Hydraulic Pump/Pump Motor Assembly
Pump Motor - 24 Volt DC motor
Pump Displacement –
10 & 15VP – .098 cu. in./rev. (1.6cc/rev.)
20VP – .049 cu. in./rev. (0.8cc/rev )
Pump Output (Max.) –
10 & 15VP - 1.20 gpm @ 2200 psi
20VP – 0.65 gpm @ 2200 psi
Hydraulic System Pressure Setting –
10 & 15VP - 68.95 bar (1000 psi)
20VP - 172.3 bar (2500 psi)
Rear Wheel Drive Motors
DriveMotors -
24 Volt DC w/perm. magnet
Right angle gear
Maintenance free sealed gear
Brake shaft and drive shaft, Integral to Motor
Parking Brake (must be released for pushing)
Batteries/Battery Charger
Batteries (2) – 12 Volt / 100 Amp Hour –
Deep CycleMarine - RV
Battery Charger –
Euro - 240 VAC/50 Hz input
U.K. - 115/230 VAC/50-60 Hz input - (switchable)
AUST. - 250 VAC/50 Hz input
24 volt, 10 amp output - with 2 amp finish
Reset Circuit Breaker
Automatic Charge Circuit
Plug Interlock Circuit
1.3 PERFORMANCE DATA
Platform Capacity(All Platforms except
Extendible)
10VP – 160 kg (350 lbs.)
15VP – 160 kg (350 lbs.)
20VP – 160 kg (350 lbs.)
Extendible Platform Capacity
Extendible Platform –120 kg* (265 lb.)
* The extendible platform is rated to carry a maximum
weight of 160 kg (350 lbs.), however a maximum of
120 kg (265 lb.) is allowed out on the platform extension.
Platform Size
Standard Platform – (66cm) x (66cm)
26 in. x 26 in.
Table 1-1.
Machine GVW and Wheel Loads
VP MODEL CONFIG.
GVW
(no load)
(1)
DRIVE WHEEL
(ea) w/rated load
(1)
CASTER
(ea) w/rated load
Kg/cm
2
(Drive)
Kg/cm
2
(Caster)
10VP
CE
(Euro/UK/Aust.)
420 kg
(930 lb.)
158 kg
(350 lb.)
52 kg
(115 lb.)
9.5 kg/cm
2
(135 psi)
4.5 kg/cm
2
(70 psi)
15VP
CE
(Euro/UK/Aust.)
615 kg
(1355 lb.)
240 kg
(530 lb.)
68 kg
(150 lb.)
13 kg/cm
2
(185 psi)
6.4 kg/cm
2
(91 psi)
20VP
CE
(Euro/UK/Aust.)
940 kg
(2072 lb.)
(2) 336 kg
(741 lb.)
(3) 225 kg
(496 lb.)
18.6 kg/cm
2
(265 psi)
18.6 kg/cm
2
(265 psi)
Note: (1.) Maximum wheel load in any configuration, with rated load.
(2.) Standard platform or with extended platform retracted.
(3.) Maximum with extended platform, extended.
