JLG 450A_AJ Series II Parts Manual User Manual
Page 138
3-4
SECTION 3 BOOM
48 to 49
Not Used
50
3841258
12
Keeper, Pin
51
4711600
AR
Flatwasher 3/8in Thin
52
4711500
2
Flatwasher 5/16in Thin
53
4751500
4
Flatwasher 5/16in Regular
54
4751600
AR
Flatwasher 3/8in Regular
55
4751800
3
Flatwasher 1/2in Regular
56
Not Used
57
1
Upright (Upper) Options:
4846366
450A Series II
4846335
450AJ Series II
58
4846336
2
Link
59
4846343
1
Link, Timing
60
4846346
1
Upright (Lower)
61
Not Used
62
1
Rest, Boom Options:
62A
3572750
450A Series II
682B
4846428
450AJ Series II
63
1
Cable, Electrical 18/2 Options (Not Shown):
4922770
Without Arctic Package
4923469
With Arctic Package
64 to 68
Not Used
69
1001141014
1
Plate, Bulkhead Shim
70
1671013
1
Cover (450A Series II with Arctic Package Only)
Ref
BOOM CABLES AND CLAMPS INSTALLATIONS
Ref
450A Series II:
0271311
Ref
ANSI/ANSI Export /CSA Specs without SkyPower
J
0271310
Ref
Australian/CE Specs wihtout SkyPower
J
0273279
Ref
All Specs with SkyPower
C
1001097502
Ref
All Specs with Arctic Package
A
1001097503
Ref
All Specs with Arctic Package & SkyPower
B
Ref
450AJ Series II:
0271122
Ref
ANSI/ANSI Export /CSA Specs without SkyPower)
J
0271206
Ref
Australian/CE Specs without SkyPower
J
0275116
Ref
All Specs without SkyPower with Arctic Package
D
1001115917
Ref
ANSI Spec without SkyPower with Communication System
A
0273280
Ref
All Specs with SkyPower
C
0275786
Ref
All Specs with SkyPower with Arctic Package
C
1001116516
Ref
ANSI Spec with SkyPower with Communication System
A
Ref
Note: For Additional Components See ELECTRICAL
SECTION
101 to 104
Not Used
105
4460425
1
Connector, Strain Relief (without SkyPower)
106 to110
Not Used
111
4751400
2
Flatwasher 1/4in Regular
112
Not Used
FIGURE 3-1. TOWER/MID BOOMS AND CYLINDERS INSTALLATION (USA BUILT MACHINES)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
