CAB
L2906H, 2906H, 3507H, 619A, 723A, 29.6LP, 29.6, 35.7 31200566 6-36
329 1001114989 1 COVER PLATE CLAMP
330 0760613 1 HEX HD CAPSCREW, 6X28mm, GR8.8
331 1001093371 1 O-RING, HVAC DRYER
401 3961951 4 CLIP
402 1001096170 1 ROUND NOZZLE
403 7028909 3 CONNECTOR
459 1001112094 1 WATER VALVE
70022817 1 KNOB
460 1001112277 1 HOSE ASSY
501 Ref AIR INTAKE COVER, (see Figure 6-3 for details)
601 70021482 1 DRYER
602 70021483 1 CLAMP
603 70022548 1 BRACKET
604 70020721 1 PRESSURE SWITCH
701 70022550 1 CONDENSOR
702 70022551 3 12V BLOWER
1001114983 Ref A/C COVER INSTALLATION, (L2906H & 29.6LP), (if equipped),
(not available to order, see items 801 thru 812 for service)
A
1001113373 Ref A/C COVER INSTALLATION, (2906H, 3507H, 619A, 723A, 29.6 & 35.7),
(if equipped), (not available to order, see items 801 thru 812 for service)
B
801 0760610 6 HEX HD CAPSCREW, M6X20, GR8.8
802 3290605 2 HEX LOCKNUT, M6X1
803 4811700 8 WASHER, 6mm
804 5200610 2 BOLT, M6X20
805 1001113430 1 A/C COVER ASSY, (includes items 901 thru 904) A
806 1001113431 2 BRACKET
807 1001114975 1 A/C TUBES COVER, (L2906H & 29.6LP)
1001114974 1 A/C TUBES COVER, (2906H, 3507H, 619A, 723A, 29.6 & 35.7)
808 1001114981 1 A/C TUBES COVER BRACKET
809 1001115013 2 A/C COVER SUPPORT
810 3933468 1 STAMPED CLIP
811 4010506 2 POZI-DRIVE PAN HD SCREW, 5X12mm
812 4811600 1 WASHER, 5mm
901 3900364 8 BUTTON HD CAPSCREW, M6X20
902 4811702 8 WASHER, 6mm
903 1001113371 1 A/C COVER, (L2906H, 2906H, 3507H, 619A & 723A)
1001113371B 1 A/C COVER, (29.6LP, 29.6 & 35.7)
904 1001113372 1 A/C GRILL, (L2906H, 2906H, 3507H, 619A & 723A)
1001113372B 1 A/C GRILL, (29.6LP, 29.6 & 35.7)
Figure 6-8 Heat & A/C Installation (Continued)
Item Part Number Qty. Description Rev.
Before S/N 1160005989
excluding 1160005189, 1160005314 & 1160005414
