Page 295
8-7
SECTION 8 DECALS
FIGURE 8-2. DECAL INSTALLATION (ANSI EXPORT SPECS)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
Ref.
DECAL INSTALLATIONS
0274093
Ref.
JLG Logo Decals
2
1001093424
Ref.
600SC - Brazil Spec Decals (Portuguese/English)
B
1001116970
Ref.
600SC - Chinese Spec Decals (Simplified Chinese/English)
B
1001116971
Ref.
600SC - Chinese Spec Decals (Traditional Chinese/English)
B
0273982
Ref.
600SC - CSA Spec Decals (English/French)
B
1001103292
Ref.
660SJC - Brazil Spec Decals (Portuguese/English)
6
0273984
Ref.
660SJC - CSA Spec Decals (English/French)
B
1001093554
Ref.
Decal - High Pressure Cylinder 600SC - Brazil Spec Decals
(Portuguese/English)
1
1001094012
Ref.
Decal - High Pressure Cylinder 600SC/660SJC - CSA Spec
Decals (English/French)
1
1
Not Used
2
1701499
6
Decal - No Lift (S/N 0300144413 to S/N 0300174703 Only)
3
1701502
1
Decal - High Oil Level (S/N 0300128000 to S/N 0300133154
Only)
4
1701503
1
Decal - Low Oil Level (S/N 0300128000 to S/N 0300133154
Only)
5
1701509
1
Decal - Manual
6
1701529
6
Decal - Arrow
7 to 9
Not Used
10
1703811
2
Decal - Tie Down /Lift
11
1703814
4
Decal - Danger/Electrocution
12
1704277
A/R
Decal - Attach Lanyard Here
13
1704412
1
Decal - Hydraulic Oil
14 to 15
Not Used
16
1704461
4
Decal - No Tie Down (S/N 0300144413 to S/N 0300174703)
17
3251243
1
Nameplate - 120V-60Hz
18 to 20
Not Used
21
1
Decal - Inspection Options:
Brazil Spec Decals (Portuguese/English)
1705901
S/N 0300128000 to S/N 0300151930
Not Required
S/N 0300151930 to S/N 0300174703
Not Required
Chinese Spec Decals (Chinese/English)
CSA Spec Decals (English/French)
1704006
S/N 0300128000 to S/N 0300151930
Not Required
S/N 0300151930 to S/N 0300174703
22
A/R
Decal - Warning/Crushing Options:
1705903
Brazil Spec Decals (Portuguese/English)
1001116845
Chinese Spec Decals (Chinese-Simplified/English)
1703943
Chinese Spec Decals (Chinese-Traditional/English)
1703942
CSA Spec Decals (English/French)
23
Not Used
24
2
Decal - No Hands Options:
1705967
Brazil Spec Decals (Portuguese/English)
1705968
Chinese Spec Decals (Chinese-Simplified/English)
1001116846
Chinese Spec Decals (Chinese-Traditional/English)
1704000
CSA Spec Decals (English/French)
