SECTION 2 - PROCEDURES
3121804
– JLG Lift –
2-25
Table 2-4. Machine Model Adjustment
Adjustment
Adjustment range
Default Values - Gas
Default Values - Diesel
DRIVE
Accel
1.0 to 5.0 sec
4
4
Decel
1.0 to 5.0 sec
2
2
FWD MIN
0 to 100%
21
21
FWD MAX
0 to 100%
48
48
FWD ELEV
0 to 35%
30
30
REV MIN
0 to 100%
21
21
REV MAX
0 to 100%
52
52
REV ELEV
0 to 35%
30
30
LO MAX
35 to 65%
50
50
ENGINE SPD
2800 to 3800 RPM
3600
3000
GAIN
0 to 999
180
50
DROOP
0 to 999
200
250
STABILITY
0 to 999
170
125
LIFT
Accel
0.2 TO 5.0
4
4
Decel
0.2 TO 5.0
0.5
0.5
UP MIN ENG
1400 TO 2200 RPM
2000
2000
UP MAX ENG
2600 to 3600 RPM
3000
3000
LO MAX
35 to 55%
50
50
GAIN
0 to 999
150
10
DROOP
0 to 999
220
240
STABILITY
0 to 999
125
70
IDLE
ENGINE SPEED
1200 TO 1500 rpm
1500
1500
GAIN
0 to 999
150
10
DROOP
0 to 999
250
85
STABILITY
0 to 999
100
90
MIN ACT
0 T0 100%
19
25
MAX ACT L/D
0 T0 100%
60
100
MAX ACT IDLE
0 T0 100%
55
40
CUT ACT
200 TO 2800 RPM
500
500
