7-2 600SC 660SJC 3121158
SECTION 7 ELECTRICAL
FIGURE 7-1. ELECTRICAL DIAGRAM LIST
ITEM # PART NUMBER QTY. DESCRIPTION REV.
Ref. Note: Diagrams with asterisks (*) are shown in the following
pages. Diagrams not shown are available from the JLG
Service Department.
Ref. COLD WEATHER ELECTRICAL DIAGRAMS
0273575/1282571 Ref. Cold Weather Package (Caterpillar Engine)
0256060/1282571 Ref. Cold Weather Package (Deutz Engine)
0257157/1282571 Ref. Cold Weather Package with Ether Start (Deutz Engines)
4932986 Ref. ENGINE SHUTDOWN ELECTRICAL DIAGRAM
(DEUTZ ENGINES)
Ref. 2500W GENERATOR ELECTRICAL DIAGRAM
4933215 Ref. 110Volt All Except CE UK & CE German Specs
4933287 Ref. 110Volt CE UK Spec
4933284 Ref. 110Volt CE German Spec
4933216 Ref. 220Volt
4933264 Ref. 7500W SKYPOWER GENERATOR ELECTRICAL DIAGRAM
Ref. GROUND CONTROL BOX ELECTRICAL DIAGRAM
4933301 Ref. Caterpillar Engine (Prior to S/N 0300099063)
4933369 Ref. Caterpillar Engine (S/N 0300099063 to S/N 0300128000)
4933298 Ref. Deutz Engine (Prior to S/N 0300085110)
4933324 Ref. Deutz Engine (S/N 0300085110 to S/N 0300099063)
4933368 Ref. Deutz Engine (S/N 0300099063 to S/N 0300128000)
4933219 Ref. HEADLIGHT & TAILIGHTS ELECTRICAL DIAGRAM
4922639 Ref. PLATFORM ELECTRICAL DIAGRAM
Ref. PLATFORM WORKLIGHTS ELECTRICAL DIAGRAM
0273486 Ref. 600SC
0273490 Ref. 660SJC
4933146 Ref. SERVICE LIGHT CABLE ELECTRICAL DIAGRAM
(AUSTRALIAN SPEC)
Ref. STANDARD ELECTRICAL SCHEMATIC
1870174* Ref. Caterpillar Engines Prior to S/N 0300099063)
1870218* Ref. Caterpillar Engines S/N 0300099063 to S/N 0300128000
1870174* Ref. Deutz Engines Prior to S/N 0300085110
1870194* Ref. Deutz Engines S/N 0300085110 to S/N 0300099063
1870218* Ref. Deutz Engines S/N 0300099063 to S/N 0300128000
