SECTION 1 - SPECIFICATIONS
1-2 – JLG Sizzor – 3120892
Lift
Up - 34-42 seconds
Down - 31-39 seconds
Platform Capacity
Standard - 455 kg (1,000 lb.)
Manual Platform Extension Capacity
115 kg (250 lb.)
Machine Weight
Approximately 2359 kg (5,200 lb.)
Wheelbase
2.0 m (78.0 in.)
Machine Height (Platform Fully Elevated)
7.9 m (26 ft.)
Machine Height (Platform Lowered)
2.3 m (89.0 in.)
Platform Railing Height
1.0 m (39.5 in.)
Machine Length
2.7 m (105.0 in.)
Machine Width
1.8 m (69.0 in.)
Ground Clearance
14.0 cm (5.5 in.)
Maximum Tire Load
921 kg (2,030 lb.) @ 1.3 bar (19 psi)
1.4 TORQUE REQUIREMENTS
All wheel lug nuts should be torqued to 122 Nm (90 ft lb)
every 150 hours.
NOTE: When maintenance becomes necessary or a fas-
tener has loosened, refer to the Torque Chart in this
section to determine proper torque value.
1.5 LUBRICATION
Hydraulic Oil
NOTE: Hydraulic oils must have anti-wear qualities at least
to API Service Classification GL-3, and sufficient
chemical stability for mobile hydraulic system ser-
vice. JLG Industries recommends Mobilfluid 424
hydraulic oil, which has an SAE viscosity of 10W-30
and a viscosity index of 152.
Aside from JLG recommendations, it is not advisable
to mix oils of different brands or types, as they may
not contain the same required additives or be of
comparable viscosities. If use of hydraulic oil other
than Mobilfluid 424 is desired, contact JLG Indus-
tries for proper recommendations.
Table 1-1. Hydraulic Oil
HYDRAULIC SYSTEM OPERATING
TEMPERATURE RANGE
SAE VISCOSITY GRADE
0 to +23 degrees F
(-18 to -5 degrees C)
10W
0 to +210 degrees F
(-18 to +100 degrees C)
10W-20,10W-30
+50 to +210 degrees F
(+10 to +100 degrees C)
20W-20
