SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
6-2 – JLG Lift – 3121324
6.2 OPERATING SPECIFICATIONS
Table 6-1. Operating Specifications
Maximum Working Height:
with outriggers deployed
with outriggers stowed
87 ft (26.5 m)
72 ft (22 m)
Maximum Platform Height:
with outriggers deployed
with outriggers stowed
80 ft (24.5 m)
65 ft (19.8 m)
Turning Radius:
Inside
Outside
14.5 ft (4.4 m)
20.3 ft (6.1 M)
Wheelbase 12.8 ft (3.9 m)
Maximum Work Load (Capacity) - Main Platform/
Platform Extension 1650 lbs
(750 kg)
Maximum Number ofPersons 2
Tools and Equipment
1300 lbs
(590 kg)
Maximum Horizontal Manual Side Force
200 lb force
(890 N)
Tilt Sensor Setting 3°
Sideslope (Machine Stowed) 5°
Gradeability (Machine Stowed) 25%
Maximum Operating Wind Speed
28 mph
(12.5 m/s)
Gross Machine Weight (Approximate)
35,935 lbs
(16,300 kg)
Drive Speed (slow)
0.4 mph (0.6 ft/sec)
(0.2 m/s)
Drive Speed (fast)
1.9 mph (2.8 ft/sec)
(0.86 m/s)
Lift Speed (platform empty)
0.89 ft/s
(0.27 m/s)
Lowering Speed (platform empty)
1 ft/s
(0.3 m/s)
Maximum Operating Hydraulic Pressure
2756 psi
(185 bar)
Power Supply Diesel Engine
Maximum Ground Bearing Pressure
152 psi
(1.05 N/mm²)
Maximum Outrigger Pad Load
17,020 lbs
(7720 kg)
Maximum Tire Load Rating
14,595 lbs
(6620 kg)
Table 6-1. Operating Specifications
