SECTION 6 - CYLINDER
3121649 E450A/E450AJ/M450AJ 243
FIGURE 6-12. JIB CYLINDER ASSEMBLY - E450AJ/M450AJ
ITEM PART NUMBER QTY DESCRIPTION REV
1001140280 Ref JIB CYLINDER ASSEMBLY A
1 70003863 1 Barrel, Weldment
2 70003864 1 Rod, Weldment
6 7026088 1 Head
7 70003833 1 Piston
8 0961951 2 Bushing
9 0961947 2 Bushing
11 4640509 2 Cartridge, Counterbalance Valve
11 2900792 2 Seal Kit - 4640509
14 7026090 2 Bushing
15 7026091 1 Sleeve
16 7026092 1 Nut
17 70002223 1 Retainer
18 See Note 1 Wiper, Rod (Note: Use p/n 70003836)
19 See Note 1 Seal, Rod (Note: Use p/n 70003836)
20 See Note 1 O-Ring (Note: Use p/n 70003836)
21 See Note 1 Ring, Back-Up (Note: Use p/n 70003836)
22 See Note 1 O-Ring (Note: Use p/n 70003836)
23 See Note 1 O-Ring (Note: Use p/n 70003836)
24 7026068 1 O-Ring
25 7024844 2 Plug
28 See Note 1 O-Ring (Note: Use p/n 70003836)
29 See Note 1 Seal, Piston (Note: Use p/n 70003836)
31 70002220 1 Ring, Retaining
32 See Note 2 Ring, Wear (Note: Use p/n 70003836)
100 70003836 1 Seal Kit (Includes Items 18-23, 28, 29 & 32)
