SECTION 1 FRAME
115
4071101
A/R
Shim
0274132
Ref.
STEERING INSTALLATION (8FT/2.4M WIDTH MACHINES)
B
201
0100011
A\R
Compound, Locking
202
0641608
6
Bolt 3/8in-16NC x 1in
203
0642012
2
Bolt 5/8in-11NC x 1-1/2in
204
0682020
12
Bolt 5/8in-11NC x 2-1/2in (Grade 8)
205
0962005
2
Bushing
206
0962131
4
Bushing
207
1683208
2
Steer Cylinder Assembly (See Section 5 for Breakdown)
208
3272001
12
Nut 5/8in-11NC (Grade 8)
209
3422426
2
Pin
210
3422429
2
Pin
211
3422430
2
Pin
212
3422900
2
Kingpin
213
3841143
6
Keeper
214
3841258
2
Keeper
215
3841285
1
Tie-Rod
216
4130401
1
Spindle (Left Side)
217
4130402
1
Spindle (Right Side)
218
4130410
2
Hub Assembly (See Items 301-311 for Breakdown)
219
4740256
2
Thrustwasher
220
4740463
2
Thrustwasher
221
4892000
2
Flatwasher 5/8in Hardened
4130410
Ref.
HUB ASSEMBLY (8FT/2.4M WIDTH MACHINES)
A
Ref.
Note: Qty is Per Assembly
301
0440170
2
Cone, Bearing
302
0440171
2
Cup, Bearing
303
0721003
3
Screw #10-24NC x 3/8in
304
1120304
2
Cap, Hub
305
2780271
1
Hub
305A
0630490
9
Stud, Wheel
306
3323403
1
Nut, Slotted 1-1/2in-12NF
307
3451010
1
Pin, Cotter 5/16in x 2-1/2in
308
3960343
1
Seal
309
4130409
1
Adapter, Spindle
310
4740283
1
Flatwasher, Hardened
311
4761000
3
Lockwasher #10
Ref.
STEERING INSTALLATION (7FT/2.1M WIDTH MACHINES)
0274257
Ref.
2WS with 7FT/2.1m Wide Frame with Tow Package
B
0274062
Ref.
4WS with 7FT/2.1m Width Frame without Tow Package
G
401
0100011
A\R
Compound, Locking
402
0100063
A\R
Loctite # RC609
FIGURE 1-2. 2WD FRONT AXLE & STEERING INSTALLATIONS (S/N 0300081836 TO S/N
0300087000) (CONTINUED)
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
