25 O
utlaw
s
pecificaTions
Overall length ....................................................................25'
Overall length w/ swim Platform ....................................26'8"
Overall length w/ Drive Down .......................................26'10"
Beam (width) .....................................................................8'2"
Draft (stern drive down) ..................................................... 38"
Draft (stern drive up in trailering position)...........................23"
Dry Weight .........................................................4,750 pounds
fuel Capacity.......................................................... 96 gallons
h
eiGhT
D
iMensions
from keel
without Windshield............................................................67"
keel To Top
Of Windshield.....................................................................71"
from Waterline
without Windshield............................................................47"
from Waterline to
Top of Windshield................................................................51"
8'2”
Beam
(fIg. 2.2.3)
B
Oat
d
iMenSiOnS
and
C
learanCeS
(F
ig
. 2.2.1)
Specification measurements are approximate
and subject to variance.
S
tern
d
rive
(i
nBOard
-O
utBOard
) e
ngine
(F
ig
2.2.2)
sTERn DRIVE UnIT
(lOWER UnIT)
DRafT
(stern Drive Down)
38"/96.52cm
WaTER lInE
hUll
(TRansOM)
EngInE
25'
26'8"
26'10"
67"
71"
