SECTION 3 - MACHINE CONTROLS AND INDICATORS
3-2 – JLG Lift – 3121606
Ground Control Station
(See Figure 3-1., Ground Control Station - 600SC, and Figure 3-2.,
Ground Control Station - 660SJC)
NOTE: The Function Enable switch must be held down in
order to operate Telescope, Swing, Lift, Jib Lift,
Platform Level Override, and Platform Rotate
functions.
1. Platform Rotate
Provides rotation of the platform.
ONLY USE THE PLATFORM LEVELING OVERRIDE FUNCTION FOR SLIGHT LEVELING OF
THE PLATFORM. INCORRECT USE COULD CAUSE THE LOAD/OCCUPANT TO SHIFT OR
FALL. FAILURE TO DO SO COULD RESULT IN DEATH OR SERIOUS INJURY.
2. Platform Leveling Override
A three position switch allows the oper-
ator to adjust the automatic self level-
ing system. This switch is used to adjust
platform level in situations such as
ascending/descending a grade.
3. Jib (If Equipped)
This switch provides raising and lower-
ing of the jib.
