SECTION 3 SCISSORS ARMS
FIGURE 3-1. SCISSORS ARMS INSTALLATION
ITEM #
PART NUMBER
QTY.
DESCRIPTION
REV.
0275623
Ref.
SCISSOR ARMS INSTALLATION
F
1
Not Used
2
0275624
1
Lift Cylinder with Valves Assembly (See Section 5 for Breakdown)
3
0701014
8
Bolt M10 x 30mm
4
0701217
2
Bolt M12 x 45mm
5
0701631
2
Bolt M16 x 140mm
6
0761215
1
Bolt M12 x 35mm
7
0762015
2
Bolt M20 x 35mm
8
3291207
2
Locknut M12
9
3291605
2
Locknut M16
10
4031612
16
Bolt M16 x 40mm
11
4031908
4
Bolt M8 x 20mm
12
4812100
4
Flatwasher M12
13
4832100
1
Lockwasher M12
14
4832500
2
Lockwasher M20
15
E000376
4
Switch, Limit
16
2160016
7
Fitting, Grease
17
S004035
2
Block, Slide
18
S007034
1
Pin
19
S007035
1
Pin
20
S007036
1
Pin
21
S200134
4
Cam
22
S201017
1
Prop, Safety
23
S201024
2
Spacer
24
S900074
1
Pin
25
S900075
1
Plate, Switch Mounting
26
0760605
4
Bolt M6 x10mm
27
3290805
1
Locknut M8
28
S900054
2
Plate, Cover
29
4811900
1
Flatwasher M8
30
4812300
4
Flatwasher M16
31
4831700
4
Lockwasher M6
32
Not Used
33
S001594
1
Bumper
34
S000142
39
Cap, Grease Fitting
35
3440816
2
Rollpin
36
S900331
A/R
Shim 2mm
37
S900332
A/R
Shim 3mm
38
0100019
A/R
Locking, Compound
39
0761015
1
Bolt M10 x 35mm
40
3291005
1
Locknut M10
41
4812000
10
Flatwasher M10
42
4831600
16
Lockwasher M5
43
E000269
4
Strain Relief, M20
44
4832000
8
Lockwasher M10
