3120798 1-3
S
E
C
T
I
O
N
1
B
A
S
E
SECTION 1 BASE
.
FIGURE 1-1. BASE MOUNTED COMPONENTS INSTALLATION
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
BASE ASSEMBLY Ref.
0259526 15VPSP Ref. C
1 0100011 Loctite #242 (Not Shown) A/R
2 to 3 Not Used
4 0630446 Bolt 3/8”-16NC x 1” (Carriage) 4
5 0641406 Bolt 1/4”-20NC x 3/4” 2
6 0641609 Bolt 3/8”-16NC x 1 1/8” 8
7 0721008 Screw 2
8 0902583 Bracket, Beacon 1
9 1060658 Cable, Brake Assembly (See Items for 201-211
Breakdown) 1
10 1702923 Decal - Manual Descent 1
11 2420165 Gauge, Hour Meter 1
12 2920146 Lamp, Beacon Assembly 1
7016319 Tube, Flash 1
7016372 Lens, Amber 1
13 3311005 Locknut #10-24NC 2
14 3311405 Locknut 1/4”-20NC 2
15 3311605 Locknut 3/8”-16NC 4
16 3740069 Relay, Power 24VDC 3
17 3911010 Screw 3
18 4160164 Spring, Compression 2
19 4300106 Stud, Grooved 4
20 4360314 Switch, Toggle 1
21 Switch, Tilt Options: 1
4360435 Prior to S/N 03863
4360465 S/N 03863 to Present
22 4460648 Receptacle - 2 Position 2
23 4711400 Flatwasher 1/4” Narrow 4
24 4740430 Washer, Fender 2
25 4751000 Flatwasher #10 Wide 7
26 4751600 Flatwasher 3/8” Wide 12
27 4846087 Base Weldment 1
28 4860175 Wheel, Rear Assembly 2
7019659 Steel Insert (1 Per Assembly) 2
29 4860177 Wheel, Caster Assembly 2
7019660 Axle 1/2” x 3 1/4” (1 Per Assembly) 2
7019661 Wheel, Replacement (1 Per Assembly) 2
7019662 Caster without Wheel (1 Per Assembly) 2
7019663 Bearing, Wheel (1 Per Assembly) 2
30 3310601 Nut #6-32 NC (S/N 13479 to Present) 8
31 3910620 Screw #6-32 NC x 1 1/4” (S/N 13479 to Present) 4
32 4750600 Flatwasher #6 (S/N 13479 to Present) 8
