Premium -86 °C Freezers — Operating manual
3. Remove the lining plate and lock barrel.
4. Insert the plastic blanking plug supplied.
5. Insert the lining plate and screw in the two screws.
6. Place freezer handle in open position and close freezer door.
The door handle has a cam action to pull the door closed and a reverse cam action to break the
seal so the door can be opened. When closing the outer door, ensure that the cam is engaged for
correct operation. The initial vacuum inside the cabinet may cause the door to appear closed, but
when the vacuum releases, the door will open. Always ensure the handle is properly engaged. It
is important that the heated vent port is kept clear. This will avoid putting undue stress on the
handle mechanism.
Hint!
It is important that the handle lock lining plate be installed at all times.
NOTICE!
Risk of material damage
 DO NOT SLAM THE DOOR WITH THE HANDLE IN THE CLOSED POSITION.
4
Installation
