Controls and Indicators

Operation Manual

Page 5

C

ONTROLS

AND

I

NDICATORS

Figure 2:

Controls and Indicators

1 Drive (Hi Speed)
2. Drive (Low Speed)
3. Level
4. Horn Button
5. Lift/Lower Button
6. Glow Plug
7. Engine Start
8. Emergency Stop Button
9. Display

10. Joystick

1. Emergency Stop
2. Elevate
3. Descend
4. Enable
5. Glow Plug
6. Start

Platform Controls

Chassis Controls

10

1

2

3

4

5

6

7

8

9

1

2

3

4

5

6
