Spyclops SPY-BULLET - Manual

SPY-BULLETG
Weatherproof IR Color Camera
Specification
Packing List
No Name Model Number
2.
User Guide
SPY-BULLETG
1
1.
Weatherproof IR Color Camera SPY-BULLETG 1
Notes: Before providing power for the
camera, please read this User Guide in
detail!
Model SPY-BULLETG
Pick up Element 1/3" SONY Super HAD CCD II
Effective Picture Elements
(H×V) NTSC:976(H)×494(V),PAL:976(H)x582(V)
Horizontal Resolution 700 TV Line
Minimum Illumination 0.001 Lux/F1.2
S/N Ratio More than 52dB
Scanning System 2:1 interface
Synchronous System Internal, Negative sync.
Auto Electronic Shutter NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s
Gama Characteristic 0.45
Video Output 1Vpp, 75Ω
Auto Gain Control Auto
Power/Current DC12V(+/-10%)/500mA
Lens 2.8-12mm Manual Zoom Lens
Dimension (mm) 200(W)x171(H)x83(D)
Weight (g) 1400
Storage Temperature -30~+60℃ RH95% MAX
Operating Temperature -10~+50℃ RH95% MAX
IR Distance 40 Meters (with ￠5X42PCS Infrared LED)
