8
12000 Label ”Min­Max”
610000 Oil SJ­27 in 0.l bottle
61200 Drain bottle 1 l multi supplied separately incl. bracket for
pipe mounting and magnet
82000 Spring f/pressure control valve
940000 Plastic insulation f/electric equipment
90000 Plastic slide f/electric equipment
960000 Cable relief
6214000 Copper washer Ø10xØ6x1 mm
6221000 Gasket f/pressure control valve
62000 Gasket f/oil filling
6241800 O­ring f/1” plug ­ 2x mm
6244000 O­ring f/rib cover 6 motor
6244200 O­ring f/rib cover /4 motor
624800 O­ring Ø47x f/1 1/2” plug
6246000 O­ring f/2” plug
620000 Socket 2 mm black
622010 Socket f/handle ­1./6­4 Ø22
62000 Rubber base f/handle Ø2x0 M8x8
62200 Rubber base f/­4000 models
6271000 Rubber grommet f/6 motor
6272000 Rubber grommet f/­4 motor
6290200 Plastic handle black Ø22 mm
612000 Bolt M8x FZB
61200 Bolt M6x0 FZB
617000 Nut M12 DIN94­8
620200 Counter nut M8 flat FZB
60000 Screw CHJ M4x FZB
68000 Unbraco boltUNF 10­2 /4”
64000 Unbraco plug 1/8”
641900 Unbraco bolt M6x16 FZB
64190 Unbraco bolt M6x2 FZB
60000 Washer ø2x11.x1. FZB
61000 Clamp f/electrical equipment
66600 Washer /16” x 0 mm 4 motor
67800 Washer Ø28. x Ø1 x 1. FZB
672700 Lock nut M8 FZB
641000 Flex hose 1/8” 1 (1) cm
6417000 Flex hose 1/8” 17 (19) cm
6420000 Flex hose 1/8” 20 (22) cm
6426000 Flex hose 1/8” 26 (28) cm
64000 Flex hose 1/8” () cm
649000 Flex hose 1/8” 9 (41) cm
640000 Flex hose 1/8” 0 (2) cm
646000 Flex hose 1/8” 64 (66) cm
646400 Flex hose 1/8” 80 (82) cm
646700 Flex hose 1/8” 110 (112) cm
696000 Spacer 17 mm
6961000 Spacer 2. mm (Ø11x1 mm)
6961200 Spacer 27 mm
696100 Spacer f/transportation tap 4 motor
697080 Unloader valve w/16.4 mm needle
6991800 Gasket 12x22x7 mm
7012000 Piston f/safety valve
702000 Hose tail nipple 1/4”
7024000 Double nipple 1/4” L= 26 mm
707000 Connection piece f/non­return valve model 12
7070600 Connection piece f/non­return valve model 12­2
7071000 T­piece 1/8”
7071400 T­piece Condor
7071400 T­piece Condor
7080010 Distributor 6 way f/18­40
7084000 Adaptor f/6­90
7110000 Screw f/pressure control valve
7140000 Housing f/pressure control valve
716000 Extension piece f/cock short
716100 Extension piece f/cock long
717001 Extension piece w/through 1/4”
7164200 Cross connector
7164900 Plug 1” f/inspection
71660 Plug 1 1/2” f/inspection ASME
7166800 Plug 2” galvanized
7172800 Spacer f/600­40/0B
7172820 Spacer f/2x600
7180000 Elbow 1/4” int./ext. KRG
7181002 Elbow 1/4” x 1/4” f/outlet
7190000 Elbow 1/8”
7190000 Elbow 1/8”
72000 Hose tail f/coupling nut 1/4”
72000 Hose tail f/coupling nut 1/4”
72000 Hose tail f/coupling nut 1/4”
72000 Hose tail f/coupling nut 1/4”
762000 Nipple f/pressure control valve
766000 Bushing 1/4” x 1/4”
766200 Bushing 1/4” x 1/4” L = mm
767100 Bushing 1/2” x 1/4”
77000 Nut f/rib cover 6 motor
7700 Nut f/rib cover motor
77000 Coupling nut 1/4”
77000 Coupling nut 1/4”
810001 Bracket f/2xM, 2xM4, 2xM6, 2xOF02, OF02, 1000,
2000 1­2l, painted
8110601 Motor foundation f/6­10, painted
811101 Motor foundation f/12­40, painted
8111611 Motor foundation f/x6, 4x, 4x4, 4xOF02, 4x6, 2x1000,
2x2000­40, painted
812000 Mounting bracket f/fan
Spare parts
