diMenSiOnS 2145 2160 2180 2210
Height to top of cab 122" (3080 mm) 122" (3080 mm) 122" (3080 mm) 122" (3080 mm)
Top of exhaust 124" (3158 mm) 124" (3158 mm) 124" (3158 mm) 124" (3158 mm)
Ground clearance 18.6" (471 mm) 18.6" (471 mm) 18.6" (471 mm) 18.6" (471 mm)
Wheel base, Standard steer
Wheel base, Ultra Steer ®
118.3" (3005 mm)
122.6" (3115 mm)
118.3" (3005 mm)
122.6" (3115 mm)
118.3" (3005 mm)
122.6" (3115 mm)
118.3" (3005 mm)
122.6" (3115 mm)
Length, Standard steer
Length, Ultra Steer ®
200.4" (5010 mm)
204.8" (5120 mm)
200.4" (5010 mm)
204.8" (5120 mm)
201.5" (5038 mm)
205.9" (5148 mm)
201.5" (5038 mm)
205.9" (5148 mm)
diMenSiOnS and SPeCifiCaTiOnS
GeneSiS 2wd/fwd 2145 2160 2180 2210
Engine type 6 cylinder Genesis Diesel, Tier II, turbo charged and air to air cooled electronic fuel injection pump control
Engine HP 196 hp (145 kW) 227 hp (169 kW) 260 hp (194 kW) 278 hp (207 kW)
PTO-HP@2100 rpm 145 hp (108 kW) 160 hp (119 kW) 180 hp (134 kW) 210 hp (157 kW)
Engine displacement / bore and stroke Displacement: 456 cu.in. (7.5 L) / bore and stroke: 4.4" x 5.0" (112 x 127 mm)
Cruise control / fuel cooler Standard / N/A Standard / N/A Standard / Standard Standard / Standard
Transmission type Genesis Full Powershift
Standard - full powershift 18 forward speeds, 9 reverse: 25 mph (40 km/h)
Straight-line shuttle shift with programming Yes
Electrical system Advanced diagnostics with 2-12 volt low maintenance 950 CCA each battery and 12 V-130 amp alternator
Standard lights Halogen - 2 headlights, 9 worklights, 2 front roof mounted
Optional lights available High intensity discharge (HID) lighting
Radar / rear wiper / washer Optional
Hydraulic type Closed Center Load Sensing, relief- 2900 psi (200 Bar)
Flow at 2100 rpm Standard: 30 GPM (117 L/min), Optional: HydraFlow ® Plus 55 GPM (208 L/min)
Number of remotes Standard: color coded system with 3 valves, Optional: 4 th valve available
Front axle - track setting, 2WD 61" to 87" (1575 mm to 2210 mm) N/A
- track setting, FWD 60" to 88" (1524 mm to 2235 mm)
- track setting, Ultra Steer ® 60" to 88" (1524 mm to 2235 mm)
Rear axle length 112" (2845 mm) 112" or 120" (2845 mm or 3050 mm)
Rear axle diameter 3.62" (92 mm) 4.13" (105 mm)
Rear axle track - width adjustable Axle A-112" 60" to 124" (1524 mm to 3150 mm)
Rear axle track - width adjustable Axle B-120" N/A 60" to 128" (1524 mm to 3255 mm)
Three-point hitch Category III
Standard (SAE) lift capacity 12,500 lbs (5670 kg) 15,000 Ibs (6804 kg)
Electronic draft sensing Standard
CaPaCiTieS 2145 2160 2180 2210
Fuel tank 110 U.S. gal (416 L) 110 U.S. gal (416 L) 110 U.S. gal (416 L) 110 U.S. gal (416 L)
Engine oil 22.5 qt (21 L) 22.5 qt (21 L) 22.5 qt (21 L) 22.5 qt (21 L)
Hydraulic system 124 qt (117 L) 148 qt (140 L) 148 qt (140 L) 148 qt (140 L)
Coolant system 26 qt (25 L) 26 qt (25 L) 28 qt (26.5 L) 28 qt (26.5 L)
PTO-SHafT 2145 2160 2180 2210
Type Wet / multi-plate clutch
Speed 540 / 1000 rpm 1000 rpm (540 rpm opt.) 1000 rpm 1000 rpm
540 rpm 1.375" (34.9 mm) dia. 6 spline 1.375" (34.9 mm) dia. 6 spline N/A N/A
1000 rpm 1.375" (34.9 mm) dia. 21 spline 1.375" (34.9 mm) dia. 21 spline 1.75" (44.5 mm) dia. 20 spline 1.75" (44.5 mm) dia. 20 spline
1000 rpm † N/A 1.75" (44.5 mm) dia. 20 spline 1.375" (34.9 mm) dia. 21 spline 1.375" (34.9 mm) dia. 21 spline
† optional output shaft
