Page 7 B101361-2-0809
P
arTs
l
isT
Index No. Description
Part Number
T3 &
T3W
T3C &
T3CW
T3N &
T3WN
T3CN &
T3CWN
1 Grill Body Top - Black B100456 B100456 B100456 B100456
2 Heat Indicator (Stainless) B101118 B101118 B101118 B101118
3 Lid Handle (Stainless) B070486 B070486 B070486 B070486
4 Foam Grip B073097 B073097 B073097 B073097
5 Retract-A-Rack B100594 B072695 B100594 B072695
6 Cooking Grid (Single) B101053 B101053 B101053 B101053
7 Briquet Rack B101061 B101061 B101061 B101061
8 Burner B101030 B101030 B101030 B101030
10 Collector Box Assembly B101212 B101212 B101212 B101212
11 Ignitor Spacer B101082 B101082 B101082 B101082
12 Ground Lug B069747 B069747 B069747 B069747
13 Radiation Shield B101045 B101045 B101045 B101045
14 Grill Body Bottom - Black B101313 B101313 B101313 B101313
15 Lid Stop Kit N/A DPA106 N/A DPA106
16 Valve Shield B101046 B101046 B101046 B101046
17 Valve Assembly (No Orifice) B101042 B101042 B101042 B101042
18 Manifold And Valve Assembly B101040 B101040 B101112 B101112
19 Electronic Ignitor B072218 B072218 B072218 B072218
20 Control Panel Assembly B101033 B101066 B101033 B101066
21 Control Panel Label B101028 B101028 B101028 B101028
22 Valve Knob R3918 R3918 R3918 R3918
23 Hose And LP Regulator B069756 B069756 N/A N/A
24 Pin, Shelf B073963 B073963 B073963 B073963
25 Burner Shield B101154 B101154 B101154 B101154
Not Shown Char-Master Briquets B058122 B058122 B058122 B058122
Not Shown Hardware Pack B101218 B101218 B101219 B101219
Not Shown Ignitor Ground Wire B101048 B101048 B101048 B101048
Not Shown Bridge Pin B057805 B057805 B057805 B057805
Not Shown Hinge Pin B057804 B057804 B057804 B057804
Not Shown Natural Gas Conversion Kit B101062 B101062 N/A N/A
Not Shown Orifice, LP 1.25mm B101111 B101111 N/A N/A
Not Shown Orifice, NAT #49 N/A N/A B101063 B101063
Not Shown Stainless Steel Cooking Grid (Single) - "W" Models Only B101282 B101282 B101282 B101282
