ADAM Audio HM1 - Manual (Page 7)

7
).
HM1 Front HM1 Back
Woofer/Subwoofer 1
Basket ø 6” / 156 mm
ART Tweeter 1
Velocity transf. ratio 4:1
Controls
Tweeter level*
0/-1.5dB/+1.5dB
General Data
Freq. response
45Hz - 35kHz
SPL max at 1m ≥ 103dB
Crossover frequencies 2200Hz
Input terminal Biwireing
Input impedance 4Ω
Power handling
sin/music
60W/100W
Efficiency ≥ 86dB/W/m
Weight 6kg
Height x Width x Depth 300 x 170 x 260mm
Warranty 10 years
Technical Data
5“ HexaCone® woofer
Bass reflex port (2x)
A.R.T. Tweeter
*The level of the tweeter can be varied in 0/-1.5dB/+1.5dB. This will produce a
considerable change in the sound characteristics, and should be used with caution. In
case you have a considerably damped room or if there is a special sound you are after,
this control will serve you well.
l 0 ll
Tweeter level switch:
l= 0
0= -1.5dB
ll= +1.5dB
Speaker terminal
