MBW GP3000-15 User Manual
Page 18
- 15 -
ITEM
PART NO.
DESCRIPTION
QTY
1.
19913
EXCITER, GP3000
1
2.
00028
BELTGUARD
1
3.
0049L
BAR, MOLD LEFT GP3000-15
1
4.
0049R
BAR, MOLD RIGHT GP3000-15
1
5.
00160
HOUSING, GP3000-15 (Includes items 3, 4, 24 & 25)
1
6.
00174
APRON, RUBBER GP3000
1
7.
00259
SHIM (as needed)
8.
00308
DECK, GP3000-15
1
9.
01011
SHOCKMOUNT
7
10.
01012
SHOCKMOUNT
2
11.
01018
BUSHING, NYLON OUTER
2
12.
01019
BUSHING, NYLON INNER
2
13.
01056
HAIRPIN
2
14.
02473
BAR, ROLL GP3000-15 (Optional)
1
15.
02710
HANDLE, GP3000-15 (Includes items 11 & 12)
1
16.
06054
HEX HEAD CAP SCREW, 5/8-18 x 5-1/2” GR8
4
17.
06921
BRACKET, HANDLE
2
18.
F042006HCS
HEX HEAD CAP SCREW, 1/4-20 x 3/4”
3
19.
F0420HN
HEX NUT, 1/4-20
3
20.
F04LW
LOCK WASHER, 1/4”
3
21.
F04SW
WASHER, 1/4”
3
22.
F051806FWS
FLANGE LOCKING SCREW, 5/16-18 x 3/4” (with Roll Bar only)
4
23.
F0518FN
FLANGE LOCKING NUT, 5/16-18” (with Roll Bar only)
4
24.
F061607FWS
FLANGE LOCKING SCREW, 3/8-16 x 7/8”
8
25.
F0616FN
FLANGE LOCKING NUT, 3/8-16
6
26.
F081305HCS
HEX HEAD CAP SCREW, 1/2-13 x 5/8”
5
27.
F081306HCS
HEX HEAD CAP SCREW, 1/2-13 x 3/4”
13
28.
F081307HCS
HEX HEAD CAP SCREW, 1/2-13 x 7/8” (with Roll Bar only)
2
29.
F08LW
LOCK WASHER, 1/2”
18
30.
F10LW
LOCK WASHER, 5/8”
4
OPTIONAL ACCESSORIES
01038
JOB CART, GP3000-15
01629
TEST MAT
02472
ROLL BAR KIT, GP3000-15 (Includes items 14, 22, 23 & 28)
07213
SPRINKLING SYSTEM KIT, GP3000-15
