You’re also given setup controls for selecting your video
device and setting your recording frame rate. For example,
you can use slower frame rates for smaller video files.
To run the recorder software, you’ll need a PC system with
Windows 95/98, Windows 2000, or Windows NT ® 4.0; an Intel ®
Pentium processor; 128 MB of RAM; 1 GB of available disk
space; and a screen capable of displaying 16 bits of color or
higher.
IP Security View
You may have an application in which you require
enhanced video-viewing capabilities. This is where you would
need our IP Security View software, which provides single
users with sophisticated view-only functions of local and
remote camera feeds.
How does this software differ from that shipped with the
IP Security Camera? The camera’s included software allows
you to view a single image captured by a single camera. The
IP Security View software, however, enables you to view up
to 16 TCP/IP video streams within a single computer screen.
These streams—displayed in a 4 x 4, split-screen format
on your computer—originate from connections made via your
LAN/WAN or the Internet to up to 16 IP Security Cameras or
IP Security CCTV Connectors (or a combination of the two).
The software features a user-friendly GUI that can be
navigated with ordinary mouse and keyboard techniques.
Adding the LC1000A cameras or LC1003A units to the IP
Security View database can be done quickly and involves
entering an IP address and assigning a port address. You can
even change your video settings from color to black and white
to increase frame refresh rates and modify bandwidth used to
improve video speed.
With its activity log, the IP Security View stores logged
activities in a database, from which you can export with
filtering capabilities to text files.
For the software, you’ll need a PC running Windows 95/98,
Windows 2000, Windows NT, or Windows XP with a screen
capable of displaying 16 bits of color or higher. A 17" or larger
monitor is recommended.
724-746-5500 blackbox.com
TECH SPECS
IP Security Camera:
Camera Sensor:
Gamma Correction — 0.45
Geometry — Zero geometric distortion
Imager —
1 ⁄
3
NTSC color CCD
Iris — Manual models: CCD iris; Auto models: Video-driving auto iris
NTSC Video Output Level — Composite, 1 Vp-p
Picture Elements — 512 horizontal x 492 vertical
Pixel Size — 9.6 x 7.5
Scanning System — 2:1 interlaced NTSC
Scene Illumination (Minimum) — 2 lux @ F1.4
Signal-to-Noise Ratio — +46 dB
Sync System — Internal sync
White Balance — Auto
Connectors:
Auto Iris Lens — (1) 4-pin square (QQQ)
Composite Video — (1) BNC, 75-ohm, analog
LAN Interface — (1) RJ-45 Category 5
Power — (1) 2-pin screw terminal
Mounts:
Camera — Top or bottom mount,
1 ⁄ 4 -20 threaded; use included mini
bracket
Lens — CS/C mount, adapter included
Performance:
Compression Rate (Maximum) — 30 fps
Nominal Frame Refresh — Color mode: Up to 15 fps;
Monochrome mode: Up to 30 fps
Resolution — 330 TV (H) 350 TVLL (V)
Video Latency —
1 ⁄
30
of a second
Power:
Power Requirements — 12-VDC, 1.5-A regulated supply
IP Security CCTV Connector:
Connectors:
Composite Video — (1) BNC, 75-ohm, analog
Control Ports — RS-232: (1) DB9 passthrough port;
RS-422/RS-485: (1) RJ-11
LAN Output — (1) RJ-45 Category 5
Relay/Alarm Extender Port — (1) DB9
Power — (1) 2-pin screw terminal
Performance:
Compression Rate (Maximum) — 30 fps
Nominal Frame Refresh: At 128 kbps: Up to 15 fps;
At 256 kbps: Up to 30 fps
Video Latency — 1 ⁄
30
of a second
Power:
Power Requirements — 5-VDC, 500-mA regulated supply
LC1003A
