Apple AirPort Extreme Base Station User Manual
Page 11
Chapter 2
Setting Up Your AirPort Extreme Base Station
11
3
Locate the two mounting bracket holes on the bottom of the base station.
4
Feed the cables through the mounting bracket and then connect them to the base
station.
The base station is designed to mount with the ports on the top (Apple logo right side
up), with the cables passing behind it through the mounting bracket as shown.
Note:
The mounting bracket has enough space for six cables (power, two Ethernet
cables, USB printer cable, a telephone cable, and external antenna cable). In most cases,
only two or three cables are used.
Mounting bracket holes
LL2870.book Page 11 Thursday, October 28, 2004 12:45 PM
