Tractor body – MTD Automatic Lawn Tractor 607 User Manual
Page 27
27
REF.
NO.
PART
NO.
DESCRIPTION
1
683-0195
Bracket Assembly
2
710-0528
Hex Cap Screw, 5/16-18 x 1.25
3
710-0599
Self-tapping Screw, 1/4-20 x .5
4
710-0751
Hex Cap Screw, 1/4-20 x .62
5
710-0895
Self-tapping Screw, 1/4-15 x .75
6
710-0896
Screw, 1/4-15 x .75
7
710-0924
Phillips Pan Screw, 1/4-20 x .75
8
712-0271
Hex Sems Nut, 1/4-20
9
712-0292
U-type Speed Nut, 1/4-20
10
712-0431
Flange Lock Nut, 3/8-16
11
726-0211
U-nut, 5/16-18
12
726-0293
Retainer Nut, 3/8
13
731-1854
Headlight Lens
14
731-2300
Hood, 7-style, Red
731-2301
Hood, 7-style, Green
731-2302
Hood, 7-style, Black
731-2303
Hood, 7-style, Charcoal Grey
15
731-2306
Hood Plenum, 7-style
16
735-0126
Rubber Washer, .87 x .33
17
736-0105
Bell Washer, .401 x .87 x .063
18
783-0475
LH Side Panel
19
783-0476A
RH Side Panel
20
783-0477
Grille
21
783-1034
Hood Bracket, 7-style
22
783-1038
Hood Side Bracket, 7-style
23
710-0106
Hex Cap Screw, 1/4-20 x 1.25
24
710-0604A
Self-tapping Screw, 5/16-18 x .625
25
710-1017
Truss Phillips Screw, 1/4-20 x .625
26
710-1238
Hex Washer Screw, 5/16-18 x .625
27
710-3217
Truss Phillips Screw, #8-32 x .375
28
712-0142
Hex Nut, #8-32
29
712-3004A
Flange Lock Nut, 5/16-18
30
712-3027
Hex Flange Lock Nut, 1/4-20
31
731-1857
Throttle Control Knob
32
731-2122
Dash Panel
33
731-2227
Parking Brake Button
34
731-2228
Plastic Plug
35
736-3078
Flat Washer, .349 x 1.0 x .063
36
747-1196
Pivot Rod
37
749-1087
Dash Support Tube
38
751-0659
Two-gallon Fuel Tank (shown)
751-0658
Three-gallon Fuel Tank
39
751-0603
Fuel Cap (Fits Either Tank)
40
710-1268
Screw, #10-16 x .375
41
783-0478A
Hood, 8-style
42
783-0551A
Hood Hinge Bracket, 8-style
43
783-0553A
Hood Support Bracket, 8-style
44
731-2247
Heat Shield‡
(Units w/ B&S OHV Twin)
731-2248
Heat Shield‡
(Units w/ B&S Opposed Twin)
45
747-1184
Heat Shield Support Rod
46
726-3046
Ratchet Clip
47
746-1085
Choke Cable/Knob †
(Units w/ B&S Opposed Twin)
—
OEM-190-603 Grille Guard™ Bumper Kit, Not Shown
(if so equipped)
AF-47442
Bumper Assembly
AF-44056
Clevis Pin, .5 x 1
AF-43055
Internal Cotter Pin
AF-44742
Plastic Plug
REF.
NO.
PART
NO.
DESCRIPTION
Tractor Body
†Tractors with a B&S Single-cylinder (I/C or OHV) engine have NO choke knob/cable. The choke is activated with the throttle control.
‡Tractors with a B&S Single-cylinder (I/C or OHV) engine have NO heat shield.
