Technical Specifications
E 87
tsn Tswana
tso Tsonga
-tsw Tswana
tuk Turkmen
tum Tumbuka
tur Turkish
tut Altaic (Other)
tvl Tuvaluan
twi Twi
tyv Tuvinian
uga Ugaritic
uig Uighur
ukr Ukrainian
umb Umbundu
und Undetermined
urd Urdu
uzb Uzbek
vai Vai
ven Venda
vie Vietnamese
vol Volapük
vot Votic
wak Wakashan languages
wal Walamo
war Waray
was Washo
wel Welsh
wen Sorbian languages
wol Wolof
xho Xhosa
yao Yao
yap Yapese
yid Yiddish
yor Yoruba
ypk Yupik languages
zap Zapotec
zen Zenaga
zha Zhuang
znd Zande
zul Zulu
12. Technical Specifications
Power supply
The MCS-D system includes devices which provide power via integrated modular power supplies (MCS-D 200 control unit,
CA 4115/30/45 power supply units) and devices which have to be powered (microphone stations, interfaces, adapters).
Power supplies
MCS-D 200 control unit (19") with integrated power supply
• Input power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150 VA, optional 250 VA
• Output power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96 W, optional 192 W
• Input voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230/115 V, 50/60 Hz
• Output voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ± 24 V
• Output current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2A, optional 4 A
CA 4115/30/45 power supply unit (19") for system extension; optional: 1 - 3 power supplies
• Input power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150 VA
• Output power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . approx. 96 W
• Output voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ± 24 V
• Output current
CA 4115 (1 modular power supply) . . . . . . . . . . . . . . . 2 A
CA 4130 (2 modular power supplies). . . . . . . . . . . . . . 4 A
CA 4145 (3 modular power supplies). . . . . . . . . . . . . . 6 A
Current consumer
CA 4522/44/66 digital / analogue interface (19") with 1 to 3 modules
• Current consumption
CA 4522: 1 x (2 IN / 2 OUT) . . . . . . . . . . . . . . . . . . . . . . approx. 100 mA
CA 4544: 1 x (4 IN / 4 OUT) . . . . . . . . . . . . . . . . . . . . . . approx. 200 mA
CA 4566: 1 x (6 IN / 6 OUT) . . . . . . . . . . . . . . . . . . . . . . approx. 300 mA
CA 4212/13/14 adapter
• Current consumption . . . . . . . . . . . . . . . . . . . . . . . . . approx. 65 mA
MCS-D 2073 microphone station
• Current consumption . . . . . . . . . . . . . . . . . . . . . . . . . approx. 115 mA
MCS-D 202 interpreter station
• Current consumption . . . . . . . . . . . . . . . . . . . . . . . . . approx. 115 mA
MCS-D 2074 service (technician) station
• Current consumption . . . . . . . . . . . . . . . . . . . . . . . . . approx. 115 mA
