ASSEMBLY
1. Remove stroller from box. The front wheels, rear wheels, child
tray, parent tray and canopies need to be installed prior to use.
2. To attach the front wheels, unfold stroller as described in the
section following. Lift front of stroller and snap each of the
front wheels onto the wheel casting steel bayonet. Ensure that
the wheels are firmly locked into place. Please see figure 1.
3. Assemble the rear wheels to the rear axle assembly as shown in
figure 2a. Slide washer onto axle. Slide wheel onto axle. Slide
the other washer onto axle. Secure wheel with the locking clip.
Snap wheel cap into place. Lean the stroller forward to rest on
the front wheels. To attach the rear wheels, position the rear axle
and wheel assembly such that the brake levers are facing to the
rear of the stroller. Press the rear wheel assembly onto the rear
frame tubes being careful that the push buttons on the forward
side of each rear tube engage the hole on the forward side of
each rear wheel housing. Pull on the rear wheel assembly to
ensure that it is securely attached to the stroller. Please see figue
2b.
Ensure that the wheels are firmly locked into place. Do Not use
the stroller if the wheels are not locked into place, but rather
contact our customer service department immediately at (800)
328-7363, between the hours of 8:00am and 4:30pm PCT, for
assistance
4. Attach the canopies by inserting the male plastic fitting on the
bottom of the canopy into the female plastic fitting on either side
of the respective seat. See figure 3. The rear seat canopy has a
skirt that must be snapped to the rear seat seatback.
5. To attach the front tray, push the tray onto the front tubes of
the stroller frame until the tray locks into place. To remove
the front tray, push the small metal ball located on each side
WARNING:
Please follow all of these instructions to ensure the
safety of your children. Keep these instructions for future reference.
WARNING:
Failure to follow these instructions could result in
serious injury or death. Avoid serious injury from falling or sliding out.
Always use the safety belts and insure that the children are properly
positioned according to these instructions.
WARNING:
Never leave children unattended.
• Purses, shopping bags, parcels, diaper bags or accessory items may change the balance of the stroller and
cause hazardous unstable conditions.
• The maximum weight that can be carried in the basket is 5 lbs and in the parent tray is 3 lbs. Excessive
weight may cause a hazardous unstable condition to exist.
• Be certain the stroller is fully erect and latched in the open position before allowing the children near the
stroller.
• Use of the stroller with three (3) children weighing more than 45 pounds each, or children totaling more
than 135 pounds, will cause excessive wear and stress on the stroller and may cause a hazardous unstable
condition to exist.
• DO NOT use the stroller on stairways or escalators.
• Never allow your stroller to be used as a toy
• To clean use only mild household soap or detergent and warm water on a sponge or clean cloth.
• Check your stroller for loose screws, worn parts, torn material or stitching on a regular basis. Replace or
repair parts as needed
• Discontinue use of stroller should it malfunction or become damaged. Please contact our customer service
Parts Hotline to arrange for repair or obtain replacement parts.
Please: If you experience any difficulty with the use of our product or have a question regarding these
instructions, please contact our Customer Service Department at (800) 328-7363 between the hours of 8:00 and
4:30 Pacific Coast Time. Please do not return the product to the store as once it is returned it cannot be re-sold
and the materials and energy used to make it are wasted.
To contact us:
BABY TREND, INC. Parts Hotline:
1567 S. Campus Ave. (800) 328-7363
Ontario, CA 91761 8:00am to 4:30pm Pacific Coast Time
Triplet Stroller
02.06
TO ENSURE SAFE OPERATION OF YOUR STROLLER, PLEASE FOLLOW THESE
INSTRUCTIONS CAREFULLY. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Stroller
Child Tray Parent Tray
Front Wheels
Rear Axle
2 Canopies Rear Canopy
Figure 1.
Figure 2a.
Figure 3.
2 3 Figure 4. Figure 4a.
Rear Wheels
Washers Clips Caps
Figure 2b.
