12J800
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
0991−12 Assemblies include all parts shown in frames. 11/30/2007
12
118 497315 Jet−Main
(High Altitude)
(Used After Code Date
02092900).
−−−−−−− Note −−−−−
497348 Jet−Main
(High Altitude)
(Used After Code Date
96060200 and Before
Code Date 02093000).
497315 Jet−Main
(High Altitude)
(Used Before Code
Date 96060300).
497315 Jet−Main
(High Altitude)
Used on Type No(s).
2368, 2369.
118A 498977 Jet−Main
(High Altitude)
(Used After Code Date
96060200).
−−−−−−− Note −−−−−
496063 Jet−Main
(High Altitude)
(Used Before Code
Date 96060300).
121 498260 Kit−Carburetor
Overhaul
125 698444 Carburetor
(Primer System)
(Used After Code Date
96060200).
−−−−−−− Note −−−−−
498170 Carburetor
(Primer System)
(Used After Code Date
95102900 and Before
Code Date 96060300).
498254 Carburetor
(Primer System)
(Used Before Code
Date 95103000).
694146 Carburetor
Used on Type No(s).
2368, 2369.
125A 498964 Carburetor
(Choke System)
Used on Type No(s).
1120, 1567.
−−−−−−− Note −−−−−
690000 Carburetor
(Choke System)
Used on Type No(s).
2905.
127 D694468 Plug−Welch
127A D691739 Plug−Welch
130 691203 Valve−Throttle
−−−−−−− Note −−−−−
696564 Valve−Throttle
(Used With Plastic
Throttle Shaft)
130A 691181 Valve−Throttle
133 398187 Float−Carburetor
134 D398188 Kit−Needle/Seat
137 zD693981 Gasket−Float Bowl
144 493824 Pulley/Spring
Assembly
146 690979 Key−Timing
159 691753 Bracket−Air Cleaner
Primer
163KzD272653 Gasket−Air Cleaner
187 791766 Line−Fuel
(Cut to Required
Length)
187A 791873 Line−Fuel
(Molded)
187B 791891 Line−Fuel
(Includes Filter)
(Used After Code Date
05063000).
−−−−−−− Note −−−−−
692042 Line−Fuel
(Includes Filter)
(Used Before Code
Date 05070100).
187C 791875 Line−Fuel
(Molded)
188 690877 Screw
(Control Bracket)
190 690940 Screw
(Fuel Tank)
202 691829 Link−Mechanical
Governor
K Included in Engine Gasket Set−Ref. No.358.
D Included in Carburetor Overhaul Kit−Ref. No. 121.
z
Included in Carburetor Gasket Set−Ref. No. 977.
∅ Included in Valve Gasket Set−Ref. No 1095.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
