Bunn FPG-2 DBC - Manual (Page 6)

6
SCHEMATIC WIRING DIAGRAM
FPG-2 DBC
N
W
H
I
W
H
I
/
B
L
K
B
L
K
L1
LEFT GATE
LIMIT THERMOSTAT
LIMIT THERMOSTAT
SOL
SOL
WHI/ORA
WHI/GRN
WHI/YEL
RED
WHI/BLK
WHI/BLK
J1-6
J1-6
J6-10 J6-5 J6-1
CONTROL PC BOARD
COIL
RELAY
RIGHT GATE
1 11
SHIELD
SWITCH UNIT ASSY
B2 C4 C5 C6 A2 A1 C3 C2 C1
WHI
RED
RED
RED
BLU
BLK
36706.0000A 03/04 © 2004 Bunn-O-Matic Corporation
120 VOLTS AC
2 WIRE
SINGLE PHASE
60 HZ
Switch Unit Assembly Codes
A1 Grind
A2 Stop
B2
Hidden Button "Right"
C1 Large Batch Size "Left"
C2 Medium Batch Size "Left"
C3 Small Batch Size "Left"
C4 Large Batch Size "Right"
C5 Medium Batch Size "Right"
C6 Small Batch Size "Right"
M
+
–
AC
AC
RECT
3
AMP
GRN
6 8
36705 031505
